Description
CARTRIMHOME C12
14.6″ Android Auto Multimedia Head Unit For Tacoma 2016-2023
- Built-in wireless CarPlay & Android Auto
- Easy Setup, Plug and Play
- Supports OEM back camera and steering wheel buttons, JBL
Please Note :
The 12+256GB version includes an HD front camera.
Allows for dashcam-like recording of front and rear cameras to an external USB drive.
Built-in Front and Rear Camera Anytime View App
Key Features
- Plug-and-play installation — no cutting or splicing required.
- Retains OEM features including backup camera, steering wheel controls, and factory USB ports.
- Fast performance powered by an 8-core processor and optimized C12 system.
- Wireless CarPlay and Wireless Android Auto built-in (CarLink).
- 32-band EQ tuning and DSP55 audio processor for premium sound.
- Supports AHD 1080p cameras, TVI, and CVBS inputs.
- Switch and run 2 apps on one screen side by side, some built-in apps do not support split screen.
Our Installation Video
Trail Tacoma Blog Post on Catrimhome C12 Head Unit
Install PDF
Return Policy
All returns are subject to a restocking fee, and the buyer is responsible for return shipping costs.
For all cancelled orders (if already shipped) or non-warranty returns, a 15% restocking fee will apply. Return shipping must be paid by the buyer. Refunds will be issued after the returned item has been received and inspected.
All returned items must be in their original packaging and in unused condition.
Tech Specs
| Platform | UIS7862 | UIS7870 |
| Android version | 12 | 13+ |
| CPU (Processor) | Unisoc UMS7862 8 cores (2x Cortex A75 + 6x Cortex A55) | Unisoc UMS7870 8 cores (1x Cortex-A76 up to 2.7GHz + 3x Cortex-A76 up to 2.3GHz + 4x Cortex-A55 up to 2.1GHz) |
| GPU | 2-core ARM Mali G52 614.4MHz | 4-core ARM Mali G57 850MHz |
| Process technology | 12nm | 6nm |
| RAM | LPDDR4 – 4GB / 8GB | LPDDR4 – 12GB |
| ROM | EMMC 64/128G | EMMC 256G |
| Resolution | 1920×1080 | |
| Support android auto / carplay | Built-in wireless CarPlay & Android Auto (CarTLink). | |
| EQ | 32-band equalizer, surround sound | |
| DSP audio processor | 4 output channels + 1 mega bass output | |
| Camera support | AHD (720p/1080p @25/30 fps) / TVI / CVBS | |
| Networks | Built-in 4G SIM Card modem (2 SIM cards) – supports calls and SMS via SIM card. TD-LTE / FDD-LTE / TD-SCDMA / HSPA(+) / WCDMA / HSPA(+) GSM / GPRS / EDGE / CDMA standards – Needs validation |
|
| Bluetooth | Qualcomm 3031 | |
| WiFi | 2.4Ghz/5GHz, IEEE802.11B/G/N compatible WLAN | |
| GPS | Navigation with GPS support, BEIDOU, GLONASS | |
| Radio module | ST TDA7708 – https://www.st.com/en/automotive-infotainment-and-telematics/tda7708.html | |
| Amplifier | TDA7851 4 x 48 W MOSFET – https://www.st.com/resource/en/datasheet/tda7851a.pdf | |
| Warranty | 1 year | |
